Description du produit
Cette excavatrice XCMG XE490D de 2019 illustre les performances éprouvées de l'un des principaux fabricants chinois d'engins de construction. Conçue pour les travaux d'excavation, de terrassement et de manutention de matériaux les plus exigeants, cette machine offre la puissance et la fiabilité requises sur les grands chantiers de construction et les sites miniers.
- Modèle : excavatrice hydraulique XCMG XE490D
- Année de fabrication : 2019
- Classe de poids en ordre de marche : environ 49 tonnes
- Système hydraulique robuste pour des cycles de creusement efficaces
- Châssis porteur durable, conçu pour une longue durée de service
- Cabine opérateur spacieuse avec commandes ergonomiques
- Actuellement située au Shandong, en Chine
- Adaptée aux travaux de carrière, à l'exploitation minière et aux grands travaux de génie civil
Cette unité représente une occasion d'acquérir un engin d'excavation lourde performant auprès d'un fabricant de confiance. Contactez-nous pour connaître l'état actuel de la machine, obtenir les rapports d'inspection disponibles et organiser l'expédition internationale vers votre chantier.
A few translation choices worth flagging: "operating weight class" → *classe de poids en ordre de marche* is the standard French technical term (the EU machinery directive uses "ordre de marche" for operating weight). "Undercarriage" → *châssis porteur* rather than the literal *train de roulement*, which in French usually implies the rolling gear specifically. If you're targeting buyers in France vs. Quebec or West Africa, I can adjust terminology — French Canadian and African B2B listings often favor slightly different renderings for "quarrying" and "heavy civil works."| Spécifications | Valeur |
|---|---|
| No. | 1166979 |
| Tonnage (tons) | 49 |
| Working weight (kg) | 48100 |
| Bucket capacity (m³) | 2.5 (2.3-3.1) |
| Boom length (mm) | 6670 |
| Rod length (mm) | 2900 |
| power | Traditional power |
| manufacturer | Made in China |
| bucket | backhoe |
| Engine type | QSM111 |
| Rated power (kw/rpm) | 280 / 2050 |
| Cooling mode | water-cooling |
| Maximum torque (N.m) | 1898 / 1300 |
| Number of cylinders (PCS) | 6 |
| Displacement (L) | 11 |
| Working form | Direct injection, 4-stroke, turbocharged, air-to-air cooling |
| Ground specific pressure (Kpa) | 85 |
| Rotation speed (rpm) | 9.2 |
| Climbing ability (%) | 35 |
| Bucket digging force (kN) | 305 |
| Rod digging force (kN) | 275 |
| Maximum tractive force (kN) | 338 |
| Travel speed (km/h) | 5.4 / 3.2 |
| Maximum flow of main pump (l/min) | 2 x 360 |
| Traveling Hydraulic Circuit (Mpa) | 34.3 |
| Rotary Hydraulic Circuit (Mpa) | 31 |
| Main pump type | 2 plunger pumps |
| Pilot Oil Circuit (MPa) | 3.9 |
| Fuel Tank (L) | 725 |
| Hydraulic Tank (L) | 430 |
| Engine Oil changes (L) | 38 |
| Total transport length (mm) | 11630 |
| Total transport width (mm) | 3582 |
| Total transport height (mm) | 3705 |
| Counterweight ground clearance (mm) | 1324 |
| Minimum ground clearance (mm) | 519 |
| Back end turning radius (mm) | 3800 |
| Onboard width (mm) | 3095 |
| Total track length (mm) | 5353 |
| Track gauge (mm) | 2750 |
| Track plate width (mm) | 600 |
| Track ground length (mm) | 4292 |
| Maximum digging radius (mm) | 11085 |
| Maximum digging depth (mm) | 6985 |
| Maximum excavation height (mm) | 10050 |
| Maximum unloading height (mm) | 6940 |
| Maximum vertical digging depth (mm) | 4400 |
| Maximum excavation radius of stop surface (mm) | 10860 |
