2019 XCMG XE490D

1/4
Acheter Pelle XCMG XE490D d'occasion / 1
Acheter Pelle XCMG XE490D d'occasion / 2
Acheter Pelle XCMG XE490D d'occasion / 3
Acheter Pelle XCMG XE490D d'occasion / 4

Description du produit

Cette excavatrice XCMG XE490D de 2019 illustre les performances éprouvées de l'un des principaux fabricants chinois d'engins de construction. Conçue pour les travaux d'excavation, de terrassement et de manutention de matériaux les plus exigeants, cette machine offre la puissance et la fiabilité requises sur les grands chantiers de construction et les sites miniers.

  • Modèle : excavatrice hydraulique XCMG XE490D
  • Année de fabrication : 2019
  • Classe de poids en ordre de marche : environ 49 tonnes
  • Système hydraulique robuste pour des cycles de creusement efficaces
  • Châssis porteur durable, conçu pour une longue durée de service
  • Cabine opérateur spacieuse avec commandes ergonomiques
  • Actuellement située au Shandong, en Chine
  • Adaptée aux travaux de carrière, à l'exploitation minière et aux grands travaux de génie civil

Cette unité représente une occasion d'acquérir un engin d'excavation lourde performant auprès d'un fabricant de confiance. Contactez-nous pour connaître l'état actuel de la machine, obtenir les rapports d'inspection disponibles et organiser l'expédition internationale vers votre chantier.

A few translation choices worth flagging: "operating weight class" → *classe de poids en ordre de marche* is the standard French technical term (the EU machinery directive uses "ordre de marche" for operating weight). "Undercarriage" → *châssis porteur* rather than the literal *train de roulement*, which in French usually implies the rolling gear specifically. If you're targeting buyers in France vs. Quebec or West Africa, I can adjust terminology — French Canadian and African B2B listings often favor slightly different renderings for "quarrying" and "heavy civil works."
SpécificationsValeur
No.1166979
Tonnage (tons)49
Working weight (kg)48100
Bucket capacity (m³)2.5 (2.3-3.1)
Boom length (mm)6670
Rod length (mm)2900
powerTraditional power
manufacturerMade in China
bucketbackhoe
Engine typeQSM111
Rated power (kw/rpm)280 / 2050
Cooling modewater-cooling
Maximum torque (N.m)1898 / 1300
Number of cylinders (PCS)6
Displacement (L)11
Working formDirect injection, 4-stroke, turbocharged, air-to-air cooling
Ground specific pressure (Kpa)85
Rotation speed (rpm)9.2
Climbing ability (%)35
Bucket digging force (kN)305
Rod digging force (kN)275
Maximum tractive force (kN)338
Travel speed (km/h)5.4 / 3.2
Maximum flow of main pump (l/min)2 x 360
Traveling Hydraulic Circuit (Mpa)34.3
Rotary Hydraulic Circuit (Mpa)31
Main pump type2 plunger pumps
Pilot Oil Circuit (MPa)3.9
Fuel Tank (L)725
Hydraulic Tank (L)430
Engine Oil changes (L)38
Total transport length (mm)11630
Total transport width (mm)3582
Total transport height (mm)3705
Counterweight ground clearance (mm)1324
Minimum ground clearance (mm)519
Back end turning radius (mm)3800
Onboard width (mm)3095
Total track length (mm)5353
Track gauge (mm)2750
Track plate width (mm)600
Track ground length (mm)4292
Maximum digging radius (mm)11085
Maximum digging depth (mm)6985
Maximum excavation height (mm)10050
Maximum unloading height (mm)6940
Maximum vertical digging depth (mm)4400
Maximum excavation radius of stop surface (mm)10860
