Description du produit
Discover the reliability and performance of the 2020 XCMG XCT20L5, now available from Inner Mongolia, China. This crane, with a main boom length of 40 meters, is equipped to meet the stringent requirements of modern construction sites. It complies with National V emission standards, ensuring environmental compliance and operational efficiency. With 3000 hours of operation and over 40,000 kilometers logged, this machine remains in excellent condition, ready to take on your next project. The XCT20L5 is a testament to XCMG's commitment to durability and quality, making it an ideal choice for businesses looking to enhance their fleet with a robust and well-maintained piece of equipment.
- Year: 2020
- Brand: XCMG
- Model: XCT20L5
- Main Boom Length: 40 meters
- Emission Standard: National V
- Operating Hours: 3000
- Mileage: Over 40,000 kilometers
- Location: Inner Mongolia, China
| Spécifications | Valeur |
|---|---|
| No. | 1108378 |
| Tonnage (tons) | 20 |
| Working weight (kg) | 21500 |
| Bucket capacity (m³) | 1.0-1.2 |
| Boom length (mm) | 5680 |
| Rod length (mm) | 2910 |
| power | Traditional power |
| manufacturer | Made in China |
| bucket | backhoe |
| Engine type | QSB7 |
| Rated power (kw/rpm) | 135/2050 |
| Cooling mode | water-cooling |
| Number of cylinders (PCS) | 6 |
| Displacement (L) | 6.7 |
| Working form | Direct injection, 4-stroke, turbocharged, air-to-air cold |
| Ground specific pressure (Kpa) | 47.5 |
| Rotation speed (rpm) | 12 |
| Climbing ability (%) | 35 |
| Bucket digging force (kN) | 157 |
| Rod digging force (kN) | 116 |
| Maximum tractive force (kN) | 184 |
| Travel speed (km/h) | 5.7/3.1 |
| Fuel Tank (L) | 400 |
| Hydraulic Tank (L) | 220 |
| Engine Oil changes (L) | 24 |
| Total transport length (mm) | 9630 |
| Total transport width (mm) | 2910 |
| Total transport height (mm) | 3100 |
| Counterweight ground clearance (mm) | 1050 |
| Minimum ground clearance (mm) | 486 |
| Minimum turning radius of front working device (mm) | 3530 |
| Back end turning radius (mm) | 2890 |
| Total track length (mm) | 4155 |
| Track gauge (mm) | 2290 |
| Total track width (mm) | 600 |
| Maximum digging radius (mm) | 9760 |
| Maximum digging depth (mm) | 6660 |
| Maximum excavation height (mm) | 9540 |
| Maximum unloading height (mm) | 6780 |
| Maximum vertical digging depth (mm) | 6480 |
